DESCRIPTION

The Harley-Davidson® Nightster™ motorcycle is the next chapter in the Harley-Davidson Sportster™ legacy – a leap forward in performance and design built on a foundation laid 65 years ago.

THIS IS THE RIGHT BIKE FOR

Fans of the classic Sportster™ silhouette paired with a Revolution™ Max engine and advanced features
Riders looking for a quick and nimble motorcycle with razor-sharp handling
Enthusiasts who appreciate the heritage and feel of a Harley-Davidson motorcycle in an understated package

Air box cover

The most obvious resemblance to its Sportster lineage is the shape of the airbox cover, which shares its profile with the classic Sportster model fuel tank.

Wheels

"The Nightster" is equipped with a 19-inch front wheel and a 16-inch rear wheel, dimensions selected to deliver nimble performance and distinctive style.

Exposed dual rear shocks

Modeled after a previous Sportster chassis, Nightster features exposed dual rear shocks that provide a critical style line at the rear of the motorcycle.

Liquid Cooled Revolution Max 975T

Performance when you need it, the Revolution Max 975T engine is a liquid-cooled V-Twin tuned to make tremendous torque at low RPM, delivering strong acceleration from the start with robust power through the mid-range.

Frame

Nightster does not use a traditional hoop-style frame. Instead, the powertrain is used as a stressed member significantly reducing weight and resulting in a very stiff chassis. Each component has been designed to be compact, strong, and lightweight.

Rider Safety Enhancements

Nightster comes equipped with a collection of technologies that are designed to increase a riderÃƒÂ¢Ã¢â€šÂ¬Ã¢â€žÂ¢s confidence during unexpected situations or while riding through adverse road conditions. Rider Safety Enhancements are designed to adjust and match motorcycle performance to available traction during acceleration, deceleration, and braking. The systems are electronic and utilise the latest chassis control, electronic brake control and powertrain technology.

Weight Distribution

Using light-weight materials and shifting components to new places has helped reduce overall weight. Centralising the mass of the engine and fuel cell location low in the chassis makes the bike feel very light, enhancing performance and improving rider confidence when mounting the bike, maneuvering at low speeds, carving through corners and when resting at a stop.

Ride Modes

Selectable Ride Modes electronically control the motorcycle's performance to better match the road conditions, or the experience you want. You can select from Road Mode, Rain Mode or Sport Mode. The system works by adjusting power delivery, engine braking, ABS and TCS settings to each specific mode.

Instrument of expression

Harley-Davidson presents Instrument of Expression, a film profiling builders whose individualism and creativity epitomise the Nightster spirit.

Makers and creators

To write the next chapter, you need the right instrument. For the makers and creators, the Nightster is the ultimate canvas for those riders who seek to push through barriers and create their own riding experience.

Dimensions

Length 2,250 mm
Seat Height, Unladen 705 mm
Ground Clearance 110 mm
Rake 30
Trail 137 mm
Wheelbase 1,545 mm
Tyres, Front Specification 100/90-19 57H
Tyres, Rear Specification 150/80B16 77V
Tyre, Type Dunlop^®Harley-Davidson Series Bias Blackwall
Fuel Capacity 11.7 l
Oil Capacity (w/filter) 4.5 l
Weight, As Shipped 211 kg
Weight, In Running Order 221 kg

Engine

Engine ² Revolution^® Max 975T
Bore 97 mm
Stroke 66 mm
Displacement 975 cc
Compression Ratio 12:1
Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
Exhaust 2-into-1; catalyst in header

Performance

Engine Torque Testing Method J1349
Engine Torque ³ 95 Nm
Engine Torque (rpm) 5000
Horsepower 67 kW
Lean Angle, Right (deg.) 32
Lean Angle, Left (deg.) 32
Fuel Economy Testing Method EU 134/2014
Fuel Economy 5.1 l/100 km

Drivetrain

Primary Drive Gear, 49/89 ratio
Gear Ratios (overall) 1st 12.21
Gear Ratios (overall) 2nd 9.022
Gear Ratios (overall) 3rd 6.994
Gear Ratios (overall) 4th 5.641
Gear Ratios (overall) 5th 4.731
Gear Ratios (overall) 6th 4.131

Chassis

Front Fork 41mm SHOWA™ Dual Bending Valve conventional forks. Aluminium fork triple clamps.
Rear Shocks Rear suspension is dual outboard, direct-acting (no linkage) emulsion technology shock absorbers with coil springs and a threaded collar for pre-load adjustment.
Wheels, Front Type ⁴ Aluminum cast, satin black
Wheels, Rear Type ⁴ Aluminum cast, satin black
Brakes, Caliper Type Front: single rotor, floating, hub - mounted; Rear: solid uniform expansion rotor

Electric

Lights (as per country regulation), Indicator Lamps All LED headlamp, low and high beam with signature position lighting; all LED rear lighting; LED bullet turn signals
Gauges 4 inch viewable round gauge area analog display with, Speedometer, L/R turn Indication, Traction Control Indication, Coolant Temperature Alert, ABS alert, Fog Lamp Indication, Battery Voltage Alert, High Beam Indicator, Low Fuel Indication, Rear-ABS Disabled Indication, Failure-Indication Alert, Neutral Position Indication, Low Tire Pressure indication, Check Engine Light indication, Oil Pressure Alert, Service Indication.

Infotainment

Screen Size 4" Analog Instrument with Segmented LCD (102 mm)
TYPE Analog Display
Languages English (default)
Vehicle Information Screen (Air Temperature, Oil Pressure and EITMS) Total Odometer (Selectable Miles or km), Trip A/B, Gear Position Indication, Fuel Range, 12/24 Hr Clock, Digital Tachometer, Segmented Feul Level, Ride Mode Indication

Rider Safety Enhancements

ANTI-LOCK BRAKE SYSTEM (ABS) Included
TRACTION CONTROL SYSTEM (TCS) Included
DRAG-TORQUE SLIP CONTROL SYSTEM (DSCS) Included

Prices listed are the ride away pricing for base models. Options such as colour are available at additional cost. Ride Away Price includes registration fees and CTP insurance where applicable. Prices subject to change without prior notice.
Recommended 91 octane (95 RON) or higher fuel (R+M)/2.
Values shown are nominal. Performance may vary by country and region.
Standard and optional wheels may vary by country and region.
Riding range estimates provided following the SAE J2982 and are based on expected performance of a fully-charged battery when operated under specified conditions. Actual range will vary depending on riding habits, ambient weather and equipment conditions.
